Defi® 5T Trainer
The Defi® 5T Trainer is a training tool for preparing emergency responders to use the AED defibrillator to treat a victim of sudden cardiac arrest.
The Trainer provides realistic simulation of the defibrillator without actually charging or discharging electrical energy. Voice prompts, simulated energy delivery, pauses for CPR, Training Pads, and the functional system status indicator all accurately mimic the operation of the defibrillator and provide a realistic demonstration.
Comes with remote control for the Trainer provides the Instructor with significant control over the configuration of the Trainer.
The remote control communicates with the Trainer via an IR window located next to the PADs connector. A status indicator LED is located next to the IR window, and it will flash to indicate that a
The remote control communicates with the Trainer via an IR window located next to the PADs connector. A status indicator LED is located next to the IR window, and it will flash to indicate that a
correct command has been received. The status indicator LED will flash continuously when a scenario has been paused. Refer to the diagram and descriptions listed below
The Defi® 5T Trainer is a training tool for preparing emergency responders to use the AED defibrillator to treat a victim of sudden cardiac arrest.
The Trainer provides realistic simulation of the defibrillator without actually charging or discharging electrical energy. Voice prompts, simulated energy delivery, pauses for CPR, Training Pads, and the functional system status indicator all accurately mimic the operation of the defibrillator and provide a realistic demonstration.
Comes with remote control for the Trainer provides the Instructor with significant control over the configuration of the Trainer.
The remote control communicates with the Trainer via an IR window located next to the PADs connector. A status indicator LED is located next to the IR window, and it will flash to indicate that a
The remote control communicates with the Trainer via an IR window located next to the PADs connector. A status indicator LED is located next to the IR window, and it will flash to indicate that a
correct command has been received. The status indicator LED will flash continuously when a scenario has been paused. Refer to the diagram and descriptions listed below
Nine different scenarios are available.
Multiple language selections are available.
Handhold Infra-red remote control allows instructors to change training sessions.
Special Features
Voice prompts identical to those in the defibrillator.
LED prompts identical to those in the defibrillator.
Remote control for instructor to use.
Multiple language selections are available.
Handhold Infra-red remote control allows instructors to change training sessions.
Special Features
Voice prompts identical to those in the defibrillator.
LED prompts identical to those in the defibrillator.
Remote control for instructor to use.
| Batteries (Trainer) | CR123A-4x2 12V d.c. 2.8Ah |
| Battery life (Trainer) | at least 150 hours |
| Battery (remote control) | 3V Lithium (CR2025) |
| Battery life (remote control) | at least 1 year |
| Number of training scenarios | 9 |
| Storage temperature without batteries | -30°C to 70°C |
| Operating temperature | 0°C to 50°C |
| Weight with batteries | 1.0 kg |
| Dimensions | 303 x 216 x 89 mm |
The Standard and Level of Electromagnetic Compatibility
| Category | Standard | Level |
| Radiated Emissions | EN55011 | CISPR 11 B |
| ESD | EN61000-4-2 | 8KV air 6KV contact |
| Radiated Susceptibility | EN61000-4-3 |
10 V/m (20 V/m EN60601-2-4) |
Standard:
AED trainer Pad .................... 1Pcs
Battery ...................................... 1Pcs
Case .......................................... 1Pcs
Remote Control ..........................1Pcs
Cleaning Cloth ........................... 1Pcs
Options:
Cabinet (5 Models available)
AED trainer Pad .................... 1Pcs
Battery ...................................... 1Pcs
Case .......................................... 1Pcs
Remote Control ..........................1Pcs
Cleaning Cloth ........................... 1Pcs
Options:
Cabinet (5 Models available)
Product Features
-
Nine different scenarios are available.
Multiple language selections are available.
Handhold Infra-red remote control allows instructors to change training sessions.
Special Features
Voice prompts identical to those in the defibrillator.
LED prompts identical to those in the defibrillator.
Remote control for instructor to use.
Product Specifications
